- Hign-concerned Chemical: None
- Processor Main Frequency: Depends on CPU
- Use: Commercial
- Memory Capacity: ≥ 4GB
- Hard Drive Capacity: 1TB
- Model Number: X6D
- Processor Brand: Intel
- Processor Model: Alder Lake-N
- Type: Mini Desktop
- Graphics Card Type: Integrated Card
- Brand Name: kingnovyPC
- Origin: Mainland China
- Certification: CE,FCC,RoHS
- Type: MINI PC
- Case Material: Brushed Aluminum Alloy
- Color: Black/Grey by random
- Memory Type: 2*DDR4 None-ECC SODIMM Ram
- Netwok Ethernet: 6*Intel 2.5G LANs
|
Processors |
Cores & Threads |
L3 Cache |
Max Turbo Frequency |
TDP |
Graphics |
|
Intel U300 |
5 cores, 6 threads |
8M |
4.40 GHz |
15W |
Intel UHD Graphics max 1.10GHz |
|
Core i3-1315U |
6 cores, 8 threads |
10M |
4.50 GHz |
15W |
Intel UHD Graphics max 1.25GHz |
|
Core i5-1335U |
10 cores, 12 threads |
12M |
4.60 GHz |
15W |
Intel Iris Xe Graphics max 1.25GHz |
|
Core i7-1355U |
10 cores, 12 threads |
12M |
5.00 GHz |
15W |
Intel Iris Xe Graphics max 1.30GHz |
Product Highlight
-6xIntel i226-V 2.5G UDE filter pure RJ45 LANs, 2xUSB3.2 Gen2(10Gbps), 2xUSB3.0, 1xType-C, 1xTF card slot.
-2xDDR4 SODIMM non-ecc ram slot, max 64GB 3200MHz.
-Support triple storage: 1xM.2 2280 PCIE4.0/3.0×4 SSD+1xM.2 2280 PCIE3.0x1 SSD+1×2.5''SATA3.0 SSD/HDD.
-1xM.2 2232 slot, support WiFi connection, also support transfer to 1xM.2 NVMe/PCIe3.0x1 2280 SSD with PCB adapter board.
-TF card slot support storage and system disk boot.
-Support three display: 1xHDMI2.1, 1xDP1.4a, 1xType-C, 3x4K@60Hz UHD video display.
-Support wide voltage 12-19V input.
-Support TPM2.0, AES-NI, ESXI, PVE, Watchdog, Auto power on, RTC, PXE boot, Wake-on-LAN etc.
-Low consumption TDP 15W and can be mounted back of monitor by VESA bracket(optional).
Package List
1xMini PC
1xPower Adapter
1xPower Cord ( we ship EU/US/UK/AU power plug base on buyer's address )
1xM.2 2232 to 2280 PCB adapter board
1xSATA Cable
1xScrews Bag
All bundles on sale DO NOT include WiFi(antennas), AC WiFi(antennas) cost US $10, AX WiFi6(antennas) cost US $30, internal 8010 fan cost US 9$. If you need, pay at this link.
Notice
Intel i226-V is a new network card, suggest to install newest version of following systems with supportable kernel: pfSense-CE 2.7, OPNsense 23.x, pfSense Plus, OpenWrt, ESXi, Proxmox 8.x, CentOS etc. Please make clear before buying, DO NOT open dispute because of system issue.
